Lumishore® EOS-LUX Command Center
Lumishore® EOS-LUX Command Center
Overview
INTEGRATE AND CONTROL YOUR ENTIRE EOS-LUX LIGHTING SYSTEM
This Command Center is the heart of your LUX above-water and full-color change underwater lighting systems, bringing every connected fixture together under one controller. Access full-spectrum color control, zone management, custom scenes and dynamic effects — including strobe, sweep, cycle and sound-to-light modes — from your compatible MFD, smart device or Lumishore display. Built-in Wi-Fi® connectivity allows for system control anywhere on board via your smartphone or tablet while automatic fixture detection makes setup fast and straightforward.
FULL-SPECTRUM COLOR CONTROL
MULTI-ZONE CONTROL
CUSTOM SCENES AND DYNAMIC EFFECTS
CONTROL VIA COMPATIBLE MFD OR LUMISHORE DISPLAY
BUILT-IN WI-FI CONNECTIVITY FOR SMART DEVICE CONTROL
3-YEAR WARRANTY
In the Box
- EOS-LUX command center
- LUX RJ45 IP68 cover kit
Specs
General | |
| Warranty | 3 years |
|---|---|
| Electrical installation | Plug and play/hard-wired |
| Operating voltage | 12 V/24 V |
| Operating voltage range | 10.5-31 VDC |
| Current consumption 12 V (max) | 0.2 A |
| Current consumption 24 V (max) | 0.1 A |
| Average power draw | 2.4 W |
| Construction | Robust weatherproof ABS (flame retardant and halogen-free) |
| Water and dust rating | IP67 |
Control Options | |
| Momentary switch | yes |
|---|---|
| Compatible MFD | yes |
| Smart device | yes |
| EOS-LUX-SUPRA display | yes |
Mounting Dimensions | |
| Dimensions (width) | 4.45" (113 mm) |
|---|---|
| Dimensions (depth) | 2.4" (61 mm) |
| Dimensions (height) | 1.3" (33 mm) |
| Mechanical installation | Screw fixings |
